LED Lub Teeb Vaj Huam Sib Luag Ceiling puas tuaj yeem txo cov nqi?



LED vaj huam sib luag qab nthab teeb txo cov nqi los ntawm 50-75% piv rau cov khoom siv fluorescent los ntawm kev siv hluav taws xob qis, kev saib xyuas tsawg, thiab kev ua haujlwm ntev ntawm 50, 000+ teev. Cov chaw lag luam raug pom zoo rau lub sijhawm them rov qab ntawm 1.5 mus rau 4 xyoo nyob ntawm cov sij hawm siv thiab cov nqi hluav taws xob.



Kev siv hluav taws xob txiav kom txuag tau tam sim



Cov txiaj ntsig tseem ceeb yog los ntawm kev txo hwj chim qis heev. Tus qauv 2x4 LED vaj huam sib luag siv 30-50 watts thaum xa tib lub teeb pom kev zoo li 90-150 watt fluorescent troffer. Qhov no txhais tau hais tias 60-70% hluav taws xob tsawg dua rau cov teeb pom kev zoo tib yam.

Rau 10,000 square feet chaw ua hauj lwm nrog 100 fixtures ua hauj lwm 2,500 teev ib xyoos twg, hloov 90-watt fluorescents nrog 40-watt LED panels txuag kwv yees li 125,000 kilowatt-teev ib xyoos twg. Ntawm ib lub teb chaws nruab nrab ntawm $ 0.12 ib kWh, uas yog $ 15,000 hauv kev txuag hluav taws xob txhua xyoo. Cov nqi siab dua hauv cov xeev xws li California ($ 0.22 / kWh) lossis New York ($ 0.18 / kWh) ua kom cov nyiaj khaws cia no sib npaug.

Qhov kev ua tau zoo yog los ntawm LED thev naus laus zis hloov pauv 95% ntawm lub zog tawm tswv yim ncaj qha rau hauv lub teeb tsis yog khib nyiab. Fluorescent fixtures poob li ntawm 80% ntawm lawv lub zog raws li cua sov, uas tsis yog tsuas yog nkim hluav taws xob xwb tab sis ua rau kom cov cua txias hauv huab cua- qhov chaw tswj.

HVAC Load Reduction Ntxiv Cov Nyiaj Pov Tseg

Cov chaw lag luam tau txais kev txuag nyiaj thib ob los ntawm kev txo cov cua txias. Txhua watt hloov mus rau cua sov los ntawm cov teeb pom kev zoo ib txwm yuav tsum raug tshem tawm los ntawm cov tshuab cua txias. Hloov 100 fixtures los ntawm 90W mus rau 40W tshem tawm 5,000 watts ntawm nruam tshav kub load.

Tshaj li lub caij txias txias, qhov kev txo cua sov no tuaj yeem txuag tau ntxiv 3,000-5,000 kWh txhua xyoo hauv HVAC lub zog. Rau cov tsev nyob hauv cov huab cua kub uas xav tau txias txias, qhov sib xyaw ua ke ntawm tag nrho lub zog txuag rau 75-80% thaum suav rau ob qho tib si teeb pom kev zoo thiab cua txias.



Kev Kho Tus Nqi Kho Mob Uas Ntev - Tus Nqi Them Nqi



LED vaj huam sib luag tshem tawm qhov rov ua dua lub voj voog hloov uas tso cov peev nyiaj nrog cov teeb pom kev zoo ib txwm muaj. Qhov nruab nrab LED vaj huam sib luag kav 50,000 mus rau 100,000 teev piv rau 10,000-15,000 teev rau cov raj fluorescent. Qhov no 5-10x lifespan ncua kev hloov pauv kev lag luam txij nkawm.

Lub 50,000 square feet warehouse nrog 500 siab -bay fixtures ntsib cov txij nkawm sib txawv nyob rau hauv txhua lub tshuab:

Fluorescent scenario: Nrog 12,000-teev nruab nrab lifespan ntawm 4,000 txhua xyoo kev khiav hauj lwm teev, txhua lub fixture yuav tsum relaming txhua txhua 3 xyoo. Ntawm $30 rau ib lub teeb ntxiv rau $80 rau kev xauj tsev thiab kev ua haujlwm, qhov ntawd yog $110 rau ib lub teeb lossis $55,000 txhua peb xyoos.

LED scenario: Nrog 60,000-teev lifespan, tib lub fixtures yuav tsum tsis muaj kev saib xyuas rau 15 xyoo. Tus nqi zam dhau 15 xyoo tag nrho yog $ 275,000 hauv cov ntaub ntawv thiab kev ua haujlwm.

Qhov kev suav no tsis suav nrog kev kho thaum muaj xwm txheej ceev thaum cov khoom siv tsis tau npaj txhij txog thaum lub sijhawm ua haujlwm, uas feem ntau raug nqi 2-3x ntau dua li kev saib xyuas vim yog kev ua haujlwm nrawm.

Kev zam tus nqi ua haujlwm nyob rau hauv siab -Cov ntawv thov qab nthab

Cov cuab yeej siv nrog 20+ ko taw qab nthab ntsib tshwj xeeb tshaj yog cov nqi kho mob hnyav. Txhua lub teeb hloov yuav tsum tau nqa cov cuab yeej siv ($ 150-300 toj ib hnub), kev cob qhia tshwj xeeb, thiab 2-3 teev ntawm downtime ib qho kev sib tw. LED panels tshem tawm cov nuj nqis rov ua dua rau 10-15 xyoo tom qab kev teeb tsa.

Lub chaw faib khoom peb tau txheeb xyuas tau siv $47,000 ib xyoos ib zaug rau siab -bay teeb pom kev zoo ua ntej lawv hloov kho LED. Tshaj tawm-retrofit, daim duab ntawd poob mus rau xoom zoo rau thawj xyoo caum ntawm kev ua haujlwm. Cov nyiaj khaws tseg 10-xyoo kev khaws cia ntawm $ 470,000 tshaj li tag nrho cov nqi ntawm $ 380,000.





Upfront Investment vs. Tag nrho cov nqi ntawm cov tswv cuab



Tus nqi teeb meem uas cuam tshuam qee qhov chaw los ntawm kev hloov kho LED yog qhov pib siv peev. Lub vaj huam sib luag coj mus muag zoo raug nqi $ 80-150 rau ib qho kev sib tw piv rau $ 30-50 rau kev xaiv fluorescent. Txawm li cas los xij, qhov kev sib piv tus nqi nqaim no tsis quav ntsej tag nrho cov tswv cuab kev lag luam.

Xav txog 300-fixture lag luam chaw ua haujlwm teeb pom kev zoo:

Fluorescent system raug nqi ntau tshaj 10 xyoo:

Cov khoom siv pib: $ 12,000

Hloov lub teeb: $ 42,000 (7 hloov lub voj voog × $ 20 / teeb × 300 fixtures)

Kev ua haujlwm rau kev hloov kho: $ 56,000 (7 cycles × $ 80 / fixture × 100 fixtures)

Fais fab mov: $180,000 (10 xyoo × 2,500 teev × 0.09 kW × 300 fixtures × $0.12/kWh)

Tag nrho: $290,000

LED system raug nqi ntau tshaj 10 xyoo:

Cov nqi pib: $ 33,000

Hloov lub teeb: $ 0

Ua haujlwm: $0

Fais fab mov: $54,000 (10 xyoo × 2,500 teev × 0.035 kW × 300 fixtures × $0.12/kWh)

Tag nrho: $87,000

LED system raug nqi $ 203,000 tsawg dua lub sijhawm 10-xyoo txawm tias 175% tus nqi siab dua. Kev them nyiaj rov qab tshwm sim hauv Xyoo 2, tom qab ntawd tag nrho cov nyiaj khaws cia ncaj qha mus rau kab hauv qab.

Utility Rebates Accelerate Payback

Ntau lub chaw muab hluav taws xob muab cov nyiaj them rov qab ntau heev rau kev hloov kho LED ua lag luam, feem ntau yog $ 20-80 ib qho khoom siv nyob ntawm kev txo qis thiab cov kev pab cuam hauv cheeb tsam. Ib qhov 500-fixture project tsim nyog rau $ 50 / qhov nyiaj rov qab tau txais $ 25,000 hauv tus nqi tam sim ntawd, txo cov peev txheej tau txais txiaj ntsig thiab txo cov nyiaj rov qab mus rau 12-18 lub hlis hauv ntau qhov xwm txheej.

Lub Database of State Incentives for Renewables & Efficiency (DSIRE) khaws cov ntaub ntawv rov qab tam sim no los ntawm ZIP code. Cov chaw yuav tsum tau soj ntsuam cov kev pab cuam no ua ntej ua tiav cov phiaj xwm phiaj xwm, vim tias cov nyiaj rov qab tuaj yeem hloov cov phiaj xwm marginal mus rau thaj chaw ROI zoo heev.



Cov nqi sib txawv ntawm cov ntawv thov



Kev txuag nqi sib txawv raws li cov qauv siv thiab hom chaw. Kev nkag siab txog cov kev hloov pauv no pab kwv yees cov txiaj ntsig tshwj xeeb:

Lub sijhawm ua haujlwm cuam tshuam: Ib qho chaw 24/7 paub txog 3x lub zog txuag ntawm kev ua haujlwm 8-teev, compressing lub sijhawm them rov qab raws li. Lub tsev kho mob xwm txheej ceev thiab cov chaw tsim khoom pom 6-12 lub hlis them rov qab thaum lub khw muag khoom qhib 50 teev txhua lub lim tiam yuav xav tau 3-4 xyoos.

Cov nqi hluav taws xob: Lub teb chaws nruab nrab ntawm $ 0.12 / kWh npog qhov ncauj qhov kev hloov pauv hauv cheeb tsam. Hawaii tus nqi $ 0.33 / kWh xa peb qhov kev txuag nyiaj ntawm Washington State tus nqi $ 0.10 / kWh rau cov qauv siv tib yam. Siab- cov cai txiav txim siab ua kom pom kev hloov kho LED txawm nyob hauv qhov tsis sib xws - siv qhov chaw.

Fixture suav thiab nkag tau yooj yim: Cov khoom siv nrog 1,000+ cov khoom siv sib kis thoob plaws ntau lub tsev ntsib qhov kev tswj xyuas qhov nyuaj dua tab sis tau txais txiaj ntsig los ntawm kev ntim nqi ntawm cov khoom siv thiab kev teeb tsa ua haujlwm. Cov chaw uas muaj kev nkag tau yooj yim (cov chav huv huv, chaw ua zaub mov, lub qab nthab siab) yuav tsum hnyav kev saib xyuas kom tsis txhob txuag nyiaj ntau dua hauv lawv qhov kev tshuaj xyuas.

Teeb pom kev zoo xav tau: Cov chaw xav tau kev ua kom muaj xim zoo nkauj (CRI 90+) rau kev tshuaj xyuas zoo lossis cov khoom muag muag them tus nqi them rau cov khoom siv LED tshwj xeeb, ncua sij hawm them rov qab los ntawm 20-40% piv rau cov khoom lag luam txheem.





Txoj Haujlwm Kev Lag Luam Tiag Los Ntawm Kev Txhim Kho Tsis ntev los no



Ib cheeb tsam 75,000 square feet retrofit ua tiav hauv 2024 hloov 680 fluorescent fixtures thoob peb lub tsev nrog LED panels. Qhov project nyiaj txiag qhia tau hais tias cov txiaj ntsig ntawm kev lag luam:

Tus nqi tsim nyog: $ 112,000 ($ 165 / fixture nrog rau kev teeb tsa)

Tus nqi them rov qab: $ 34,000

Net peev: $78,000

Kev txuag hluav taws xob txhua xyoo: $ 41,000

Kev txuag nyiaj txhua xyoo: $ 18,000

Tag nrho cov nyiaj khaws cia txhua xyoo: $ 59,000

Yooj yim them rov qab: 1.32 xyoo

10-xyoo kev txuag nyiaj: $ 512,000

Hauv paus tsev kawm ntawv tus nqi hluav taws xob ntawm $ 0.14 / kWh thiab 3,200 teev ua haujlwm txhua xyoo tsim kev lag luam zoo. Cov cheeb tsam qis dua - tus nqi nrog cov sij hawm ua haujlwm txo qis yuav pom 2-3 xyoo them rov qab.

Lub chaw tsim khoom xyoo 2023 siab -bay upgrade qhia ib zaj dab neeg sib txawv. Lawv 240 hlau halide fixtures (400W txhua) tau hloov nrog 180W LED siab-bays:

Project nqi: $186,000

Rebate: $21,600

Net peev: $164,400

Kev txuag hluav taws xob txhua xyoo: $ 58,000

Kev txuag nyiaj txhua xyoo: $ 31,000 (tshem tawm cov nqi xauj tsev)

Tag nrho cov nyiaj tau los txhua xyoo: $ 89,000

Yooj yim them rov qab: 1.85 xyoo

Lub 6,240-teev kev ua haujlwm ib xyoos ib zaug (peb zaug) thiab kev tiv thaiv tus nqi kho tseem ceeb tau tsim tshwj xeeb ROI txawm tias ntau dua rau - cov nqi kho mob rau cov khoom lag luam qib.



Txoj Kev Them Nyiaj Rov Qab



Cov chaw soj ntsuam kev hloov kho LED yuav tsum suav lawv cov nyiaj them rov qab tshwj xeeb siv cov qauv no:

Kauj ruam 1: Txiav txim siab tus nqi hluav taws xob txhua xyoo tam sim no

Tam sim no fixture wattage × fixture suav × txhua xyoo ua hauj lwm teev ÷ 1,000 × hluav taws xob tus nqi=txhua xyoo kWh nqi

Kauj ruam 2: Xam cov nqi hluav taws xob txhua xyoo LED

LED fixture wattage × fixture suav × txhua xyoo ua hauj lwm teev ÷ 1,000 × hluav taws xob tus nqi=LED kWh nqi

Kauj ruam 3: Txiav txim siab kev txuag hluav taws xob txhua xyoo

Kauj Ruam 1 tau tshem tawm Kauj Ruam 2 tshwm sim=kev txuag hluav taws xob txhua xyoo

Kauj ruam 4: Xam suav nyiaj txij nkawm txhua xyoo

(Tam sim no lub teeb lifespan nyob rau hauv cov xuab moos ÷ txhua xyoo ua hauj lwm teev) × (cov nqi teeb + nqi zog) × fixture suav=kev tu txhua xyoo tam sim no

Tus nqi kho LED (feem ntau yog $0 rau thawj 10 xyoo)=$0

Kev tu txhua xyoo tam sim no rho tawm LED txij nkawm=kev txuag nyiaj txhua xyoo

Kauj ruam 5: Xam tag nrho qhov project tus nqi

(LED fixture nqi + installation nqi) × fixture suav=tag nrho cov nqi project

Tus nqi tag nrho qhov project rho tawm cov nyiaj rov qab=net project cost

Kauj ruam 6: Txheeb xyuas lub sijhawm them rov qab

Net project tus nqi ÷ (kev txuag hluav taws xob txhua xyoo + kev txuag nyiaj txhua xyoo)=them rov qab hauv xyoo

Ib qho piv txwv 100-fixture office: 90W fluorescents → 40W LEDs, 2,500 teev txhua xyoo, hluav taws xob $ 0.12 / kWh, $ 40 / fixture installation nqi, $ 30 rebate / fixture:

Lub zog tam sim no: 90W × 100 × 2,500 ÷ 1,000 × $ 0.12=$ 2,700 / xyoo

LED lub zog: 40W × 100 × 2,500 ÷ 1,000 × $ 0.12=$ 1,200 / xyoo

Kev txuag hluav taws xob: $ 1,500 / xyoo

Kev txuag nyiaj: $ 1,000 / xyoo (kwv yees)

Tag nrho cov nyiaj khaws cia: $ 2,500 / xyoo

Tus nqi ntawm qhov project: ($120 + $40) × 100 − ($30 × 100)=$13,000

Them nyiaj rov qab: $13,000 ÷ $2,500=5.2 xyoo



Cov txiaj ntsig zais qhov txiaj ntsig dhau qhov kev txuag ncaj qha



Ntau qhov kev txo nqi tsis ncaj feem ntau mus rau qhov tsis muaj nuj nqis hauv kev suav nyiaj rov qab yooj yim:

Txo cov nqi pov hwm hluav taws kub: LED vaj huam sib luag tsim 80% cua sov tsawg dua fluorescent lossis HID fixtures, txo cov hluav taws kub. Qee lub tuam txhab tuav pov hwm txo cov nqi them los ntawm 2-5% rau cov chaw uas muaj txhua yam-LED teeb pom kev zoo, tshwj xeeb tshaj yog nyob rau hauv warehouses khaws cov khoom tawg.

Txhim kho kev ntsuas kev tsim khoom: Lub Chaw Tshawb Fawb Teeb pom kev zoo pom tias cov xim zoo tshaj plaws thiab txo qis flicker hauv cov tshuab LED cuam tshuam nrog 3-8% kev tsim khoom tau txais txiaj ntsig hauv kev sib dhos thiab tshuaj xyuas cov haujlwm. Rau 50 tus neeg ua haujlwm qhov chaw nrog cov nyiaj hli nruab nrab ntawm $ 50,000, txawm tias qhov nce 3% txhais tau tias yog $ 75,000 hauv tus nqi txhua xyoo.

Txo cov nqi pov tseg: Fluorescent raj muaj mercury thiab yuav tsum tau tshwj xeeb cov pov tseg pov tseg ntawm $ 1-3 ib lub raj. Ib qho chaw hloov 500 lub raj txhua 3 xyoos txuag tau $ 1,500-4,500 ib lub voj voog hauv cov nqi pov tseg thiab kev tswj hwm nyiaj siv ua haujlwm.

Cov khoom depreciation: LED fixtures feem ntau tsim nyog rau lub sij hawm luv luv luv nqi raws li IRS Tshooj 179, tso cai rau kev txiav tawm tam sim ntawd tsis yog ntau - xyoo depreciation. Cov txiaj ntsig ntawm lub sijhawm no txhim kho cov nyiaj ntsuab ntws rau cov se- cov chaw them nyiaj.



Thaum LED hloov kho kom tsawg dua kev lag luam



Txawm hais tias muaj kev lag luam muaj zog hauv ntau qhov xwm txheej, qee qhov xwm txheej ua rau ncua kev siv sijhawm:

Tsawg- thaj chaw siv: Chav tsev cia khoom, chaw kho tshuab, thiab lwm qhov chaw siv tsawg dua 500 teev ib xyoos twg yuav xav tau 10+ xyoo rau kev them rov qab. Tshwj tsis yog cov khoom siv uas twb muaj lawm xav tau hloov pauv lawm, cov no yuav tsum yog qhov tseem ceeb dua.

Cov khoom siv nrog kev hloov kho teeb pom kev tsis ntev los no: Cov tsev uas txhim kho T8 los yog T5 fluorescent systems nyob rau hauv 3 lub xyoo dhau los -5 xyoo yuav tsis pom kev txuag nyiaj ntau. Tos kom txog thaum cov kab ke mus txog qhov kawg -ntawm-lub neej ua kom muaj kev lag luam loj tshaj plaws.

Cov chaw ib ntus: Kev tsim kho cov tsheb thauj khoom, qhov chaw ua yeeb yam ib ntus, thiab luv luv- cov neeg xauj tsev yuav tsis ua haujlwm ntev txaus kom paub txog kev them rov qab, tshwj xeeb tshaj yog tias cov khoom siv yuav tsum tau muab tshem tawm thaum tsiv tawm - tawm.

Cov nqi hluav taws xob tsawg heev: Ib txhais tes ntawm cov nroog uas muaj hluav taws xob hluav taws xob lossis cov nyiaj siv hluav taws xob hnyav muaj cov nqi qis dua $ 0.06 / kWh. Txawm hais tias kev hloov kho LED tseem ua rau muaj txiaj ntsig zoo ROI, 5-7 xyoo kev them nyiaj rov qab yuav tsis ua raws li cov neeg lag luam teeb meem piv rau lwm txoj kev nqis peev.
